CCR908U283SK Case

$1653.99

8U 28" Deep Roto Shock Rack

Includes Adjustable Rail Conversion System (ARCS)
Patent pending compound hinged doors
Rear rails
Casters
Shock and water resistant
Gasketed doors
Pressure relief valve
Stainless steel key-lockable field replaceable latches
Removable 4″ casters standard
Stacks securely with the wheels on or off
Recessed latches
Adjustable elastomer shock absorbers
Provisions to add additional shocks
Roto molded for strength

Case has a Lifetime Warranty

Description

28 inch Heavy Duty Shockrack systems include a revolutionary new patented Adjustable Rail Conversion System. This ARCS technology allows the user to adjust the rack width up to 0.5 inches on each side and optional easy-mount adapter rails will convert the equipment mounting standard from 3/16″ threaded to 7/32″ through holes or square cage nut windows. The 7/32″ through hole option and the 3/16″ threaded are special order items. Accommodates Dell and Compaq servers utilizing “Versa-rail” or “Rapid-rail” pull-out systems.

Square hole rack rails allow the use of replaceable 10-32 screw size cage nuts. Cage nuts and mounting screws are included and (6mm )metric cage nuts and mounting screws are available as a special order)..

This case has all of the same great features as the 24″ deep Roto Shock Series. Standard features include: (patent pending) compound hinged doors, black powder coated stainless steel latches, removable 4″ casters. The inner rack chassis is built of high strength / lightweight aluminum alloy and 11 gauge hot rolled carbon steel rack rails to DIA-310 standards. Shock and vibration mitigation is accomplished with eight (8) elastomeric isolators rated for a payload range of 40 lbs. to 150 lbs. in a standard configuration and up to 300 pounds in a special order extended payload configuration allowing adequate sway space for ambient air circulation and heat dissipation with black powder coated stainless steel latches, gasketed doors and pressure relief valve.

Product Specifications

Interior Dimensions29.25"L x 19.00"W x 14.00"H
(743mm x 483mm x 355.6mm)
Shipping Weight88.00 LBS (estimated weight of the product with packaging such as a cardboard box)
(39.92 kg)
CharacteristicsWaterproof, Shippable, Lifetime Warranty, Crushproof, Outdoor Use
HardwareWheels (Casters (set of 4)), Hinged Lid, Removable Lid, Built in Locks (option), Pressure Equalization Valve
Manufacturing MethodRotationally Molded
Manufacturing OriginUnited States of America
Case MaterialPlastic
Rackable Depth28.00 in
Shock AbsorptionElastomer Shock Absorbers
Extended Title8U 28" Deep Roto Shock Rack
Rack Units Total8
Depth Front Rail to Back Lid 33.75"
Rackable Depth 29.25"
Lid Depth 4.50"
